8K Mirror Finish Duplex 2205 Sheet for Pharmaceutical Bioreactor Vessels with Corrosion Resistance
| Herkunftsort | China |
|---|---|
| Markenname | TISCO, ZPSS,BAOSTEEL,LISCO,JISCO |
| Zertifizierung | SGS,ISO,CE,BIS |
| Modellnummer | 200 REIHE, 300 REIHE, 400 REIHE, 904l, 2205,2507 etc. |
| Min Bestellmenge | 1 Tonne |
| Verpackung Informationen | Exportseeangemessene Verpackung mit hölzerner Palette und gut gebunden und oder hinsichtlich der Anf |
| Lieferzeit | 3~10 TAGE, die meisten Größen sind auf Lager |
| Zahlungsbedingungen | L/C, T/T, Western Union |
| Versorgungsmaterial-Fähigkeit | 2000 t/Monat |
Produktdetails
| Produktname | 8K-Hochglanz-Duplex-2205-Blatt für pharmazeutische Bioreaktorgefäße | Standard | ASTM A240/240M; ASME SA-240/SA-240M; JIS G4305; DIN/BS/NF EN10028-7; ISO; GB/T 3280-2015 |
|---|---|---|---|
| Proben | Frei zu versorgen | Grad | 2507,2205,201,304, 304L 316, 316L, 430, 410, 420, 316Ti, 321, 301, 309,309S, 310, 310S, etc. |
| Width*Length | 1000*2000; 1219*2438; 1219*3048; 1250*3000; 1500*3000; 1524*3048mm oder pro besonders angefertigt | Technik | Kalt gerollt oder heiß gerollt |
| Rand | Mühlrand; Schnittkante | Oberfläche | NO.1, 2B, BA, 8K, No.4, HL, SB, geprägt, kariert, ETC…. |
| Dicke | Kaltgewalzt: 0.3mm~6mm; Warm gewalzt: 3mm~60mm | Handelsbegriff | UHRKETTE, CIF, EXW, CFR, DDU, DDP, DAP |
Sie können die gewünschten Produkte ankreuzen und im Message Board mit uns kommunizieren.
| Beenden | Definition | |
|---|---|---|
| Nr. 1 | Warmgewalzt | |
| Nr. 2B | Kaltgewalzt, helle Oberfläche; |
Produkt-Beschreibung
8K Mirror Finish Duplex 2205 Sheet for Pharmaceutical Bioreactor Vessels
Our 8K mirror finish duplex 2205 sheets combine high strength, excellent cleanability, and superior corrosion resistance specifically designed for pharmaceutical bioreactor internals.
Problem & Solution
Challenge: Austenitic 316L bioreactors have lower strength, requiring thicker walls, and may suffer pitting from cleaning agents containing chlorides.
Solution: Duplex 2205 provides higher strength (reducing wall thickness) and mirror finish prevents biofilm formation. It also resists pitting from acidic sanitizers.
Technical Specifications
| Parameter | Details |
|---|---|
| Grade | 2205, 2507 |
| Thickness | 1-5mm |
| Finish | 8K mirror, BA |
| Standard | ASTM A240M, ASME BPE (on request) |
Applications
- Bioreactor walls
- CIP spray balls
- Sanitary piping
- Fermenter baffles
Performance Characteristics
The 8K mirror finish (Ra ≤0.1µm) minimizes bacterial adhesion. Duplex microstructure provides high yield strength (≥450 MPa) for pressure cycles.
Selection Guidelines
For CIP with >200 ppm chlorides, choose 2205. For high-pressure steam cycles, 2507 is stronger. Ensure ASME BPE surface roughness certification.
Frequently Asked Questions
Is 2205 magnetic?
Yes, slightly due to ferrite phase.
Can it be electropolished?
Yes, improves passivation.
Does mirror finish affect weldability?
No, but protect surface during welding.
